7 inch 800*800 lcd display module AT070TN83 V1/LW700AT9309 replacement module
- Type:TFT, TFT
- Display Size:7"
- Supplier Type:Manufacture
- Place of Origin:Guangdong, China
- Brand Name:ND
- Size:7inch
- Resolution:800*480
- Brightness:500
- Backlight:LED
- Contrast Ratio:500:1
- Viewing Angle:50/70/70/70
- Weight:130g
7 inch 800*800 lcd display module AT070TN83 V1/LW700AT9309 replacement module
| Screen Size | 7" |
| Aspect Ratio | 15:9 |
| Display Mode | Transmissive |
| Resolution | 800X3(RGB)X480 |
| PPI ( Pixel per inch ) | 133 |
| Module/Panel Size(mm) | 165 x 104 x 4.4 |
| Active Area(mm) | 152.4 x 91.44 |
| Dot Pitch(mm) | 0.0635(W) X 0.1905(H) |
| Viewing Angle (Tpy.)θT/θB/θL/θR | 50/70/70/70 |
| Viewing direction | 6 O'Clock |
| NTSC | 50% |
| Luminance(nits) | 500 |
| Contrast Ratio | 500 |
| Response Time(ms) | 25 |
| Weight (g) | 130 |
| Interface | 40pin, 18bit RGB connector |
| Operation Temperature | -20~70 |
| Storage Temperature | -30~80 |
More information from Shenzhen New display CO.,LTD
1. Agent Brand:
* AUO/CPT/CMO/ /Innolux/ TianMa five brands tft lcd moulds, you can get the most competitive price for real products;
2.Application of our lcd panles:
Our products are widely used for banking machines, communication tools, household appliances, automobile instruments, mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.
3. Quality to be ensure:
All the panels are 100% original and brand new, no fake panels exists, so from Shenzhen New display you can enjoy the real panels directly from original factory;
Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them;4.long-term partner:
* Products are sold to more than 20 countries, so from Shenzhen New display you can get more stable supplying promise;
5. Super After-Sale service:
Shenzhen New display will support original factory technology service before and after sale for all your project, you can send all the fack panel back and here return you a new panel;
6.the best TFT LCD solution:
*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/
To get the latest prices, pls feel free to contact us.
