21.5inch lcd display board PCBA controller board mother board
minimum order
1 piece
Country of Origin
Shenzhen
Quantity:
$15.00 - $20.00
/ piece
- Type:Other
- Display Size:21.5"
- Supplier Type:manufacture
- Place of Origin:Guangdong, China
- Brand Name:New display
- type:AD board
21.5inch lcd display board PCBA controller board mother board
| OSD LANGUAGE | Simplified chinese , traditional Chinese , English , Frech , German , Itain, Spanish, Portuguese, Japanese, korean (optional ) |
| Panel | panel type : LED/ LCD |
| Interface : single /dual lvds (8bit ) | |
| Max resolution : 2048x1152 | |
| PC- RGB format, up to 2048x1152 @60Hz | |
| HDMI 480i, 480p , 576p, 720p, 1080i , 1080p | |
| PC Audio , earphone input, 0.2~2.0Vrms | |
| Frequency response 100hz ~14khz @±3dB | |
| Max output power 2x1w(8Ω) THD+N<10% | |
| Requirment : 12v DC /12V (bulit)/12v,5v(built in) /12v, 5v, 5VSB (bulit in) | |
| To panel : 3.3v/5v/ 12v | |
| Management : standby power consumption <0.5w (board only ) | |
| KEY FUNCTION | POWER, MENU , VOL +, VOL-,AD JUST/EXIT |
| OSD LANGUAGE | Simplified chinese , traditional Chinese , English , Frech , German , Itain, Spanish, Portuguese, Japanese, korean (optional ) |
| Panel | panel type : LED/ LCD |
| Interface : single /dual lvds (8bit ) | |
| Max resolution : 2048x1152 | |
| PC- RGB format, up to 2048x1152 @60Hz | |
| HDMI 480i, 480p , 576p, 720p, 1080i , 1080p | |
| PC Audio , earphone input, 0.2~2.0Vrms | |
| Frequency response 100hz ~14khz @±3dB | |
| Max output power 2x1w(8Ω) THD+N<10% | |
| Requirment : 12v DC /12V (bulit)/12v,5v(built in) /12v, 5v, 5VSB (bulit in) | |
| To panel : 3.3v/5v/ 12v | |
| Management : standby power consumption <0.5w (board only ) | |
| KEY FUNCTION | POWER, MENU , VOL +, VOL-,AD JUST/EXIT |
