4.3" AUO LCD Panel

4.3" 480x272 AUO LCD Panel G043FW01 V0 integrated led backlight

G043FW01 V0
minimum order
5 pieces
Supply Ability
20000pieces / Month
Country of Origin
HK
Quantity:
USD18.00 - USD28.00 / pieces
Contact Now
add to cart
  • Place of Origin:TW
  • Model Number:G043FW01 V0
  • Brand Name:AUO
  • Type:TFT
  • size:4.3"
  • resolution:480*272
  • Luminance:450 cd/m2
  • backlight:LED
  • Weight:68g
  • Interface:TTL
  • Viewing Angle:50/55/65/65

4.3"480x272 AUO LCD Panel G043FW01 V0 integrated led backlight

Applications:

industrial control and car application lcd panel.besides,we have different size lcd panel apply to different fileds. such as tablet pc ,health care, Digital video cameras, digital cameras, portable DVD player, visual doorbell,.


Specifications:


Items

speciation

Screen Diagonal(inch)

4.3"

resolution

480RGB(H)×272(V)

Active Area

95.04(H)×53.856(V)

Pixel Pitch(mm)

0.18 x 0.18

Pixel Arrangement

R.G.B. Vertical Stripe

brightness

450nits

backlight

LED

viewing angle

50/55/65/65

Display Mode

TN, Normally White

Nominal Input Voltage VDD(volt)

3.3 typ.

Weight(gram)

68 (max.)

Physical Size(mm)

105.7(H) × 67.4(V) × 4.19(D) (typ.)

Electrical Interface

Digital TTL 8bit

Surface Treatment

Anti-Glare, Hardness 3H

Color Depth

16.7M Colors

The most suitable view angle

6 o’clock

RoHS Compliance

RoHS Compliance

More information from Shenzhen New display CO.,LTD

1. Agent Brand:

* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd moulds, you can get the most competitive price for real products;

2.Application of our lcd panles:

Our products are widely used for banking machines, communication tools, household appliances, automobile instruments,

mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.

3.Quality to be ensure:

All the panels are 100% original and brand new, no fake panels exists, so from Shenzhen New display you can enjoy the

real panels directly from original factory;

Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the

packages have labels and serial number, you can check them;

4.Quickly delivery:

We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and

to avoid Value Added Tax in china for you, so from Shenzhen New displayyou can get more convenient delivery;

5.long-term partner:

* Products are sold to more than 20 countries, so from Shenzhen New display you can get more stable supplying promise;

6. Super After-Sale service:

Shenzhen New display will support original factory technology service before and after sale for all your project, you can send

allthefack panel back and here return you a new panel;

7.the best TFT LCD solution:

*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/

To get the latest prices, pls feel free to contact us.
