lcd display module supplier

4.5 inch high resolution 1920*1080 ips lvds lcd panel with capacitive touch screen

ND045FHD123P60 A10
minimum order
1 piece
Country of Origin
shenzhen
Quantity:
$10.00 - $20.00 / piece
Contact Now
add to cart
  • Type:TFT lcd
  • Display Size:4.5"
  • Supplier Type:factory
  • Place of Origin:Guangdong, China
  • Brand Name:ND
  • size:4.5"
  • Resolution:1920*1080
  • module size:106.34(W) * 99.46 (H) * 2.32 (T) mm
  • View angle:80/80/80/80
  • Brightness:350 nits
  • Interface:lvds

4.5 inch high resolution 1920*1080 ips lvds lcd panel with capacitive touch screen



















































































Product typeModule
Screen Size4."
Aspect Ratio16:9
Display ModeTransmissive
Resolution1920X3(RGB)X1080
Module/Panel Size(mm)106.34(W) * 99.46 (H) * 2.32 (T) mm
Active Area(mm)100.8(W) * 56.7(H) mm

PIXEL ARRANGEMENT

LVDS
surface treatmentAnti-glare
Viewing Angle (Tpy.)θT/θB/θL/θR80/80/80/80
Viewing direction6 O'Clock
NTSC50%
Luminance(nits)350
Contrast Ratio500
Response Time(ms)25
interfaceLVDS
Operation Temperature( °C)-20~70
Storage Temperature (°C)-30~80
HTHH.(op)60°C,90% RH
