8 inch 1024*768 IPS lcd panel with hdmi controller board
YX080TI01-40NM01
minimum order
1 piece
Supply Ability
200000piece / Month
Country of Origin
Shenzhen
Quantity:
USD25.00 - USD30.00 / piece
- Place of Origin:CN;GUA
- Type:TFT
- Brand Name:New display
- Model Number:YX080TI01-40NM01
- size:8"
- Resolution:1024*768
- backlight:LED
- Viewing Angle (Tpy.):80/80/80/80
- Interface:LVDS
8 inch 1024*768 IPS lcd panel with hdmi controller board
Items | speciation |
Screen Diagonal(inch) | 8" |
resolution | 1024x3(RGB) x 768 |
capacitive touch screen | muti- capacitive touch screen |
Pixel Pitch(mm) | 0.231x 0.231 |
contrast ratio | 500:01:00 |
brightness | 300nits |
backlight | LED |
viewing angle | 80/80/80/80 |
Display Mode | TN, Normally White |
Nominal Input Voltage VDD(volt) | 3.3 typ. |
Weight(gram) | 120 |
Physical Size(mm) | 174.00(w)*136.00(H)*2.45(T) |
Interface | LVDS |
Surface Treatment | Anti-Glare, Hardness 3H |
support Color | 262K |
The most suitable view angle | 6’clock |
RoHS Compliance | RoHS Compliance |
