5" tft FHD IPS lcd panel 1080p 1080*1920 with hdmi-mipi driver board
Y050SND01.1
minimum order
1 piece
Supply Ability
200000piece / Month
Country of Origin
ShenZhen
Quantity:
USD80.00 - USD85.00
/ piece
- Place of Origin:CN
- Type:TFT
- Brand Name:New display
- Model Number:Y050SND01.1
- size:5"
- resolution:1080*1920
- view angle:80/80/80/80
- Module/Panel Size(mm):64.2 (H) * 116.8(V) * 1.36(T)
- display color:16.7M
- Luminance(nits):450
- Contrast Ratio:10000
- driver IC:R69338
- interface:MIPI DSI
5"tft FHD IPS lcd panel 1080p 1080*1920 for smart phone
Screen Size | 5" |
Resolution | 1080*1920 |
Module/Panel Size(mm) | 64.2 (H) * 116.8(V) * 1.36(T) |
Active Area(mm) | 61.8 (H)×110(V) |
Viewing Angle (Tpy.)θT/θB/θL/θR | 80/80/80/80 |
Pixel Pitch | 63 |
Luminance(nits) | 450 |
| Display Mode | tft |
driver IC | R69338 |
interface | MIPI DSI |
Storage Temperature (°C) | -20~70 |
More information from Shenzhen New display CO.,LTD
