8 inch lcd module

8 inch 40-pin 1024*600 touch screen lcd module

ND080GHL40AC
minimum order
1 piece
Supply Ability
200000piece / Month
Country of Origin
Shenzhen
Quantity:
USD10.00 - USD30.00 / piece
Contact Now
add to cart
  • Place of Origin:CN
  • Display Size:8 inch
  • Model Number:ND080GHL40AC
  • Brand Name:New display
  • Type:TFT
  • size:8"
  • Resolution:1024 * 3(RGB) *600
  • Module/Panel Size(mm):192.8*116.9*6.4
  • Active Area(mm):176.64 * 99.36
  • backlight:LED
  • brightness:500

8 inch 40-pin 1024*600 touch screen lcd module

Screen Size8"
Aspect Ratio6:9
Display ModeTransmissive
Resolution1024X3(RGB)X600
PPI ( Pixel per inch )149
Module/Panel Size(mm)192.8×116.9×6.4
Active Area(mm)176.64 × 99.36
Dot Pitch(mm)0.0575(W)X0.1656(H)
Viewing Angle (Tpy.)θT/θB/θL/θR70/75/75/75
Viewing direction6 O'Clock
NTSC70%
Luminance(nits)500
Contrast Ratio700
Response Time(ms)25
Weight (g)TBD
Interface40pin FPC,
'LVDS
Operation Temperature( ℃)-20~80
Storage Temperature (℃)-30~80
HTHH.(op)60℃,90% RH
