4.3" lcd module

4.3 inch 480*272 800nits high brightness sunlight readable lcd module

YX043THL09-40C
minimum order
5 pieces
Supply Ability
200000pieces / Month
Country of Origin
shenzhen
Quantity:
USD10.00 - USD20.00 / pieces
Contact Now
add to cart
  • Place of Origin:CN
  • Type:TFT
  • Brand Name:newdisplay
  • Model Number:YX043THL09-40C
  • size:4.3"
  • Resolution:480*272
  • module size:105.5 x 67.2 x 4.05
  • View angle:50/70/70/70
  • Brightness:800
  • Interface:40pin FPC,

4.3 inch 480*272 lcd screen with capacitive touch screen

Product typeModule+T/P
Screen Size4.3"
Aspect Ratio16:09
Display ModeTransmissive
Resolution480X3(RGB)X272
PPI ( Pixel per inch )128
Module/Panel Size(mm)105.5 x 67.2 x 4.05
Active Area(mm)95.04 x 53.856
Dot Pitch(mm)0.066(W) X 0.198(H)
surface treatmentAnti-glare
Viewing Angle (Tpy.)θT/θB/θL/θR50/70/70/70
Viewing direction6 O'Clock
NTSC50%
Luminance(nits)800
Contrast Ratio500
Response Time(ms)25
Weight (g)58
Interface40pin FPC,
Parallel 24bit RGB
Operation Temperature( °C)-20~70
Storage Temperature (°C)-30~80
HTHH.(op)60°C,90% RH
StatusMP


More information from HKSEBO New display CO.,LTD

1. Agent Brand:

* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd moulds, you can get the most competitive price for real products;

2.Application of our lcd panles:

Our products are widely used for banking machines, communication tools, household appliances, automobile instruments, mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.

3.Quality to be ensure:

All the panels are 100% original and brand new, no fake panels exists, so from Yasen Daco you can enjoy the real panels directly from original factory;

Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them;

4.Quickly delivery:

We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and to avoid Value Added Tax in china for you, so from Yasen Dacoyou can get more convenient delivery;

5.long-term partner:

* Products are sold to more than 20 countries, so from Yasen Daco you can get more stable supplying promise;

6. Super After-Sale service:

Yasen Daco will support original factory technology service before and after sale for all your project, you can send all the fack panel back and here return you a new panel;

7.the best TFT LCD solution:

*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/

To get the latest prices, pls feel free to contact us.
