8.5" AUO 800x480 tft lcd module G085VW01 V0 integrated LED backlight

Items

speciation

Screen Diagonal(inch)

8.5"

resolution

800x3(RGB) x 480


Active Area

184.8(H) x 110.88(V)


Pixel Pitch(mm)

0.231x 0.231

Pixel Arrangement

R.G.B. Vertical Stripe

contrast ratio

500:01:00

brightness

300nits

backlight

LED

viewing angle

80/60/80/80

Display Mode

TN, Normally White

Nominal Input Voltage VDD(volt)

3.3 typ.

Weight(gram)

250

Physical Size(mm)

210.0(W) x 134(H) x 10.0(D) (typ.)

Electrical Interface

CMOS I/F

Surface Treatment

Anti-Glare, Hardness 3H

support Color

262K

The most suitable view angle

6’clock

RoHS Compliance

RoHS Compliance
