Innolux 5.6 inch 640 *480 lcd display panel hdmi AT056TN53 V.1

AT056TN53 V.1

minimum order

5 pieces

Supply Ability

200000pieces / Month

Country of Origin

Shenzhen

Quantity:

USD20.00 - USD30.00 / pieces

Contact Now

add to cart

Place of Origin:TW
Model Number:AT056TN53 V.1
Brand Name:Innolux
Type:TFT
size:5.6"
Resolution:640*480
backlight:LED
brightness:350
Interface:TTL

Innolux 5.6 inch 640 *480 lcd display panel hdmi AT056TN53 V.1

Screen Size	5.6''
Aspect Ratio	4:03
Display Mode	Transmissive
Resolution	640X3(RGB)X480
PPI ( Pixel per inch )	144
Module/Panel Size(mm)	126.5 x 100.0 x 5.7
Active Area(mm)	112.896 x 84.672
Dot Pitch(mm)	0.0588(W) x 0.1764(H)
Viewing Angle (Tpy.)θT/θB/θL/θR	50/70/70/70
Viewing direction	6 O'Clock
NTSC	50%
Luminance(nits)	350
Contrast Ratio	500
Response Time(ms)	25
Weight (g)	83
Interface	40pin FPC, Parallel 18bit RGB
Operation Temperature( ℃)	-20~70
Storage Temperature (℃)	-30~80
HTHH.(op)	40℃,90% RH
Status	MP

More information from ShenZhen New display CO.,LTD

1. Agent Brand:

* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd module , you can get the most competitive price for real products;

2.Application of our lcd panles:

Our products are widely used for banking machines, communication tools, household appliances, automobile instruments, mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.

3.Quality to be ensure:

All the panels are 100% original and brand new, no fake panels exists, so from NEW Displayyou can enjoy the real panels directly from original factory;

Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them;

4.Quickly delivery:

We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and to avoid Value Added Tax in china for you, so from NEW Displayyou can get more convenient delivery;

5.long-term partner:

* Products are sold to more than 20 countries, so from NEW Display you can get more stable supplying promise;

6. Super After-Sale service:

NEW Display will support original factory technology service before and after sale for all your project, you can send all the fack panel back and here return you a new panel;

7.the best TFT LCD solution:

*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/

To get the latest prices, pls feel free to contact us.
