10.4 Inch Industrial LCD Panel 1024*768 Resolution 400 Nits LVDS Interface CLAA104XA02CW
- Place of Origin:CN
- Type:TFT
- Brand Name:Customized
- Model Number:CLAA104XA02CW
- Size:10.4 inch
- Resolution:1024*768
- Brightness:400
- Backlight:LED
- Interface Type:LVDS
10.4 Inch Industrial LCD Panel 1024*768 Resolution CLAA104XA02CW
Panel Size | 10.4 inch(panel diagonal) |
Display Area (mm) | 211.2(H)×158.4(V) (10.4-inch diagonal) |
Number of Pixels | 1024(H) × 3(RGB) × 768(V) |
Pixel Pitch (mm) | 0.20625 x0. 20625 |
Color Pixel Arrangement | RGB vertical stripe |
Display Mode | Normally white |
Number of colors | 262,144 |
Brightness | 400(typ.) |
Response Time (Tr+Tf) | 25 ms |
Module Size (mm) | 236(W)×174.3(H)×7.4(D) (with PWB and component) |
Viewing Angle | 140 degree(H),120 degree(V) |
Power Consumption(W) | 4.3W |
BL unit | LED |
Electrical Interface(data) | LVDS |
Viewing Direction | 6 o´clock (Max contrast ratio, Gray Level Inversion) |
Weight(g) | TBD |
More information from Shenzhen New display CO.,LTD
1. Agent Brand:
* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd moulds, you can get the most competitive price for real products;
2.Application of our lcd panles:
Our products are widely used for banking machines, communication tools, household appliances, automobile instruments, mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.
3.Quality to be ensure:
All the panels are 100% original and brand new, no fake panels exists, so from Yasen Daco you can enjoy the real panels directly from original factory;
Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them;
4.Quickly delivery:
We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and to avoid Value Added Tax in china for you, so from Yasen Dacoyou can get more convenient delivery;
5.long-term partner:
* Products are sold to more than 20 countries, so from Yasen Daco you can get more stable supplying promise;
6. Super After-Sale service:
Yasen Daco will support original factory technology service before and after sale for all your project, you can send all the fack panel back and here return you a new panel;
7.the best TFT LCD solution:
*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/
To get the latest prices, pls feel free to contact us.
