11.6" TFT LCD display module 1366*768 LCD panel for Notebook
B116XAN02.3
minimum order
5 pieces
Supply Ability
20000pieces / Month
Country of Origin
HK
Quantity:
USD1.00 - USD50.00 / pieces
- Place of Origin:TW
- Type:TFT
- Brand Name:AUO
- Model Number:B116XAN02.3
- Size:11.6 inch
- Resolution:1366*768
- Brightness:300 nits
- Backlight:LED
- Interface:LVDS
- View angle:85/85/85/85
- Contrast Ratio:800:1
- Operating temp:0 ~ 50
- RoHS Compliance:RoHS Compliance
- Response Time:25ms
11.6"TFT LCD display module 1366*768 LCD panel for Notebook
Items | speciation |
Screen Diagonal(inch) | 11.6" |
screen format | 16:9 |
resolution | 1366*768 |
Active Area | 256.125(H) x 144(V) |
Pixel Pitch(mm) | 0.1875 X 0.1875 |
Pixel Arrangement | R.G.B. Vertical Stripe |
contrast ratio | 800:1 |
Brightness | 300 nits |
Backlight | LED |
viewing angle | 85/85/85/85 |
Display Mode | Normally Black |
Nominal Input Voltage VDD(volt) | 3.3 typ. |
Weight(gram) | 170 (typ.) |
Physical Size(mm) | 267.5 (H) x 158(V) x 4.5(D) (typ.) |
Electrical Interface | LVDS |
support Color | 16.7M colors ( RGB 6-bit+Hi FRC ) |
The most suitable view angle | 6’clock |
RoHS Compliance | RoHS Compliance |
