AUO industrial 12.1" tft lcd module 1024x768 G121XN01 V0
- Place of Origin:CN;GUA
- Products Status:Stock
- Model Number:G121XN01 V0
- Brand Name:AUO
- Interface Type:USB
- Resolution:1024*768
- Type:Other
- Screen Size:12.1"
AUO industrial 12.1"tft lcd module 1024x768 G121XN01 V0
Specifications:
Module number | G121XN01 V0 |
Resolution | 1024x768 |
Pixel Pitch | 0.240 x 0.240 (mm) |
Active Area | 245.76(H) x 184.32(V) (mm) |
View angle | R/L/U/D 80/80/80/80 (Deg) |
Mode | TN |
LCD Surface | Anti-glare,3H |
Number of Colors | 262K/16.2M |
Electrical Interface | Digital, LVDS(1ch, 6/8 bit) |
Brightness | 500 cd/m2 |
Contrast ratio | 700:01:00 |
Outline dimension | 279.0(H)x 209.0(V) x 9.0(D)(mm) |
Gross weight | 495g (Max.) |
Backlight | WLED |
LED Life (hrs.) | 50K |
Power Consumption (W) | 9.15(Typ.) |
Supply Voltage (V) | 3.3V |
Response time | 35 (ms) |
Operate temperature | -30-85 (°C) |
Storage temperature | -30-85 (°C) |
Operate humidity | 5-95 (%RH) |
Storage humidity | 5-95 (%RH) |
More information from ShenZhen New display CO.,LTD
1. Agent Brand:
* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd moulds, you can get the most competitive price for real products;
2.Application of our lcd panles:
Our products are widely used for banking machines, communication tools, household appliances, automobile instruments, mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.
3.Quality to be ensure:
All the panels are 100% original and brand new, no fake panels exists, so from Yasen Daco you can enjoy the real panels directly from original factory;
Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them;
4.Quickly delivery:
We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and to avoid Value Added Tax in china for you, so from Shenzhen New displayyou can get more convenient delivery;
5.long-term partner:
* Products are sold to more than 20 countries, so from ShenZhen New displayyou can get more stable supplying promise;
6. Super After-Sale service:
New display will support original factory technology service before and after sale for all your project,
you can send all the fack panel back and here return you a new panel;
7.the best TFT LCD solution:
*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/
To get the latest prices, pls feel free to contact us.
