CHIMEI 3.5 inch 320x240 350nits tft lcd display LQ035NC111
LQ035NC111
minimum order
1 piece
Country of Origin
shenzhen
Quantity:
$8.00 - $12.00 / piece
- Type:TFT
- Display Size:3.5"
- Place of Origin:China
- Brand Name:CHIMEI
- Resolution:320*240
- dot size:73x 219
- module size:76.9(W) * 63.9(H) * 2.80(D)
- active area:70.08(H) * 52.56(V)
- Brightness:350nits
- Interface:Digital 24-bit RGB/SERIAL RGB/CCIR656/CCIR601
- Backlight:LED
- Contrast Ratio:500:1
- Viewing Angle:70 / 70 / 50 / 70 (L/R/U/D)
- Operating Temperature:-20~+70 ( C)
CHIMEI 3.5 inch 320x240 350nits tft lcd display LQ035NC111
| LCD size | 3.5" |
| Resolution | 320*240 |
| Color Pixel Arrangement | RGB vertical stripe |
| Display Mode | Normally white,TN |
| module size | 76.9(W) * 63.9(H) * 2.80(D) |
| active area | 70.08(H) * 52.56(V) |
| Response Time (Tr+Tf) | 15ms |
| Brightness | 350nits |
| contrast ratio | 400:1 |
| Interface | digital 24-bit RGB |
| Weight | 40 |
| Panel power consumption | TBD |
| Surface Treatment | Hard Coating |
