Cheap china lcd TV display with VGA and DVI board
- Place of Origin:CN;GUA
- Model Number:HR230WU1-400
- Brand Name:BOE
- Type:TFT
- size:23"
- resolution:1920x1080
- brightness:250 nits
- Backlight:LED
- Interface:LVDS
- View angle:89/89/89/89
- Contrast Ratio:1000:1
- Operating temp:-30~85
- RoHS/Halogen Free:RoHS/Halogen Free
Cheap china lcd TV display with VGA and DVI board
Module number | HR230WU1-400 |
Resolution | 1920x1080 |
Pixel Pitch | 0.2652(H) ×0.2652(V) |
Active Area | 509.184(H) × 286.416(V) |
View angle | 89/89/89/89 |
Mode | Normal Black |
Pixel arrangement | RGB Vertical stripe |
Support Color | 16.7M |
Electrical Interface | LVDS Interface with 2 pixel / clock |
Brightness | 250 cd/m2 |
Contrast ratio | 1000:1 |
Outline dimension | 533.2(H) × 312(V) × 10.5(D) typ. |
Gross weight | 2390 g |
Backlight | LED |
LED Life (hrs.) | 30000 |
Supply Voltage (V) | 12.8V |
Response time | 14 (ms) |
Operate temperature | 0~+50 (°C) |
Storage temperature | -20~+60 (°C) |
More information from Shenzhen New display CO.,LTD
1. Agent Brand:
* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd moulds, you can get the most competitive price for real products;
2.Application of our lcd panles:
Our products are widely used for banking machines, communication tools, household appliances, automobile instruments,
mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.
3.Quality to be ensure:
All the panels are 100% original and brand new, no fake panels exists, so from Shenzhen New display you can enjoy the
real panels directly from original factory;
Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the
packages have labels and serial number, you can check them;
4.Quickly delivery:
We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and
to avoid Value Added Tax in china for you, so from Shenzhen New displayyou can get more convenient delivery;
5.long-term partner:
* Products are sold to more than 20 countries, so from Shenzhen New display you can get more stable supplying promise;
6. Super After-Sale service:
Shenzhen New display will support original factory technology service before and after sale for all your project, you can send
allthefack panel back and here return you a new panel;
7.the best TFT LCD solution:
*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/
To get the latest prices, pls feel free to contact us.
