9 inch lcd panel controller board raspberry pi kit monitor
YXD090GQ40A3
Quantity:
38.00 - 38.00
- Place of Origin:CN;GUA
- Type:TFT
- Brand Name:new display
- Model Number:YXD090GQ40A3
- product:9 inch lcd panel controller board raspberry pi kit monitor
- Resolution:1024X600
- Module/Panel Size(mm):9inch
- Outline dimension:210.7(H)x126.5(V)x5.1mm
- Display area:196.608(H)x114.15(V)
- Pixel arragement:RGB vertical stripe
- Display mode:Normally black
- AD board:hdmi board
Product Description
9 inch lcd panel controller board raspberry pi kit monitor
| Screen Size | 9inch (diagonal) |
| Aspect Ratio | 16:9 |
| Display Mode | normally black |
| Resolution | 1024 RGB(H) X600(V) |
| Pixel pitch | 0.192(H)x0.19025(V)mm |
| Module/Panel Size(mm) | 210.7(H)x126.5(W)x5.1(D)mm |
| Active Area(mm) | 196.608(H)x114.15(V)mm |
| Pixel arrangement | RGB vertical stripe |
| Surface treament | Antiglare , hard -coating (3H) |
| Weight | 240 |
| Back -light | Single LED (side - light type) |
| Power consumption (logic system ) | 0.3(max) |
| Power consumption(B/L systerm ) | 2.769(max) |
| operating temperature | -20-65℃ |
| Storage temperature | -20-80℃ |
| AD board | hdmi/vga controller board |
| Viewing angle | 80x80x80x80 |
| Interface | 40pin FPC |
| Operation Temperature( ℃) | -20~70 |
| Storage Temperature (℃) | -30~80 |
Pls note : whole set inculding 9"1024*600 lcd panel+ hdmi driver board set
