15 inch 1024x768 tft lcd module with LED backlight G150XTN03.0
- Place of Origin:TW
- Type:TFT
- Brand Name:AUO
- Model Number:G150XTN03.0
- size:15"
- resolution:1024x768
- brightness:250 cd/m2
- Backlight:LED
- Interface:LVDS
- View angle:80/80/70/70
- Contrast Ratio:700:1
- Operating temp:0~65
- RoHS Compliance:RoHS Compliance
15 inch 1024x768 tft lcd module with LED backlight G150XTN03.0
Module number | G150XTN03.0 |
Resolution | 1024x3(RGB) x 768 |
Pixel Pitch | 0.297 x 0.297 |
Active Area | 304.128(H) x 228.096(V) |
View angle | R/L/U/D 80/80/70/70 |
Mode | TN, Normally White |
Surface Treatment | Anti-glare, Hardness 3H |
Support Color | 16.2M / 262K colors |
Electrical Interface | 1 channel LVDS |
Brightness | 250 cd/m2 |
Contrast ratio | 700:01:00 |
Outline dimension | 326.5(H)x 253.5(V) x 12.0(D) (max.) |
Gross weight | 1.10kgs (Max.) |
Backlight | LED |
LED Life (hrs.) | 30K |
Response time | 8 (ms) |
Operate temperature | 0~65 |
More information from Shenzhen New display CO.,LTD
1. Agent Brand:
* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd moulds, you can get the most competitive price for real products;
2.Application of our lcd panles:
Our products are widely used for banking machines, communication tools, household appliances, automobile instruments,
mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.
3.Quality to be ensure:
All the panels are 100% original and brand new, no fake panels exists, so from Shenzhen New display you can enjoy the
real panels directly from original factory;
Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the
packages have labels and serial number, you can check them;
4.Quickly delivery:
We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and
to avoid Value Added Tax in china for you, so from Shenzhen New displayyou can get more convenient delivery;
5.long-term partner:
* Products are sold to more than 20 countries, so from Shenzhen New display you can get more stable supplying promise;
6. Super After-Sale service:
Shenzhen New display will support original factory technology service before and after sale for all your project, you can send
allthefack panel back and here return you a new panel;
7.the best TFT LCD solution:
*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/
To get the latest prices, pls feel free to contact us.
