tft lcd display

10.1" 1280*800 ips 40 pin lvds lcd screen displays

N1118-D101H69-28S
minimum order
1 piece
Supply Ability
200000piece / Month
Country of Origin
Shenzhen
Quantity:
USD25.00 - USD40.00 / piece
Contact Now
add to cart
  • Place of Origin:CN;GUA
  • Type:TFT
  • Brand Name:ND
  • Model Number:N1118-D101H69-28S
  • size:10.1"
  • Resolution:1280*800
  • dot pitch:0.0565(W) *0.1695(H) mm
  • Module/Panel Size(mm):228.6(W) *149.2(H) *2.6(MAX) mm
  • backlight:LED
  • brightness:350nits
  • Interface:LVDS

10.1"1280*800 ips Socket conenctor lvds lcd screen displays

LCD size

10.1"

Resolution

1280RGB*800 ,1024*600 optional

Display Mode

Transmissive
Normally Black

dot pitch

0.0565(W) × 0.1695(H) mm

module size

228.6(W) ×149.2(H) ×2.6(MAX) mm

active area

216.96(W) × 135.60(H) mm

Response Time (Tr+Tf)

30ms

Brightness

350 nit(typ)

contrast ratio

800:01:00

Interface

50PIN TTL /40PIN FPC LVDS/Socket conenctor lvds interface optional

Weight

165g(Max)

0.9W (Typ.)

Panel power consumption

0.9W (Typ.)

Surface Treatment

Hard Coating
