lcd display

replacement model for 10.4" 1024*768 Resolution LCD/400 Nits LCD module CLAA104XA02CW

ND104XG02-L30 V2
minimum order
1 piece
Country of Origin
HK
Quantity:
$55.00 - $60.00 / piece
Contact Now
add to cart
  • Type:TFT, TFT
  • Display Size:10.4"
  • Place of Origin:Guangdong, China
  • Brand Name:ND
  • Size:10.4inch
  • Resolution:1024*768
  • Brightness:400
  • Backlight:LED
  • Interface Type:LVDS
  • Display Area (mm):211.2(H)*158.4(V) (10.4-inch diagonal)
  • Application:car application
  • Display mode:IPS

replacement model for 10.4"1024*768 Resolution LCD/400 Nits LCD module CLAA104XA02CW









































































Panel Size



10.4 inch(panel diagonal)



Display Area (mm)



211.2(H)×158.4(V) (10.4-inch diagonal)



Number of Pixels



1024(H) × 3(RGB) × 768(V)



Pixel Pitch (mm)



0.20625 x0. 20625



Color Pixel Arrangement



RGB vertical stripe



Display Mode



Normally white



Number of colors



262,144



Brightness



400(typ.)



Response Time (Tr+Tf)



25 ms



Module Size (mm)



236(W)×174.3(H)×7.4(D) (with PWB and component)



Viewing Angle



140 degree(H),120 degree(V)



Power consumption(W)



4.3W



BL unit



LED



Electrical Interface(data)



LVDS



Viewing Direction



6 o´clock (Max contrast ratio, Gray Level Inversion)



Weight(g)



TBD
