8 inch 1024*678 open frame touch lcd monitor
NDSG08
minimum order
1 piece
Supply Ability
200000piece / Month
Country of Origin
Shenzhen
Quantity:
USD60.00 - USD90.00 / piece
- Place of Origin:CN;GUA
- Brightness:350cd/m
- Model Number:NDSG08
- Brand Name:ND
- Response Time:12ms
- Pixel Pitch:0.01
- Panel Type:IPS
- Products Status:Stock
- Contrast Ratio:1000:1
- Widescreen:Yes
- Interface Type:DVI
- Resolution:1024*768
- Application:medical
- Interface Type:USB
- Screen Size:13.3
- Title:NDSG08
- Resolution:1024*768
- backlight:LED
- Viewing Angle (Tpy.):85/85/85/85
- Package Dimensions:186*145*35mm
- Enclosure Material:Aluminium Alloy
8 inch 1024*678 open frame touch lcd monitor
| Model Number | NDSG08 |
| Display Type | 8"IPS LCD |
| Power supply | DC 5V-12V and Micro USB 5V |
| Screen Ratio | 16:09 |
| Resolution | 1024*768 |
| Outline size | 320x200x8mm |
| Connector | Micro USB+ Audio Input+Speakers |
| Contrast | 1000:01:00 |
| Brightness | 350cd/m2 |
| Response Time | 13/5 (Typ.)(Tr/Td) ms |
| Viewing Angle | Horizontal(left/right): 178°(89°/89°) Horizontal(left/right): 178°(89°/89°) |
| Support Colors | 16.7M |
| Frequency(H/V) | 30~80KHz, 60-75Hz |
| Backlight | LED backlight |
| Language | Chinese,English, Francais, Italiano, Deutsch, Espanol, Russian etc. Color system PAL/ NTSC |
| Power Consumption | 25W |
| Standby power consumption | 0.5W |
| Package Dimensions | 186*145*35mm |
| Package Standard | Carton Box |
| Interface | USB |
| Plug | AU,EU,USA,UK plug available |
| Color | Silver/blue/red |
| Enclosure Material | Aluminium Alloy |
| working Temperature | -10 to 60°C |
| storage Temperature | -20 to 70°C |
| Weight | 700g |
