Hot Sale 1.5 Inch 128x128 Resolution OLED LCD Display Panel Small Color E-Paper Modules
YX-2828GDEDF11
minimum order
1 piece
Quantity:
$10.00 - $10.00
/ piece
- Type:OLED, TFT
- Display Size:1.5"
- Place of Origin:Guangdong, China
- Brand Name:Yasen
- product:hot sale 1.5 inch resolution color small OLED lcd display panel
- resolution:128*128
- Display Color:262,144 Colors (Maximum)
- Drive Duty:1/128 Duty
- Weight:3.75 (g)
- Interface:bits 68XX/80XX Parallel, 3-/4-wire SPI
- Driver IC:SSD1351
- Size:1.5 Inch
Specification
Display Mode | Passive Matrix |
Display Color | 262,144 Colors (Maximum) |
Drive Duty | 1/128 Duty |
Number of Pixels | 128 (RGB) × 128 |
Panel Size | 33.80 × 34.00 × 1.60 (mm) |
Active Area | 26.855 × 26.864 (mm) |
Pixel Pitch | 0.07 × 0.21 (mm) |
Pixel Size | 0.045 × 0.194 (mm) |
Weight | 3.75 (g) |
Interface | 8-bits 68XX/80XX Parallel, 3-/4-wire SPI |
Drive IC | SSD1351 |
Company Profile
Why Choose Us
Experience | 10 years+ experience in LCD display customized solutions |
Production Ability | 3 automotive production lines |
Quality Control | ISO 9001 Certificated |
Certification Gurantee | SGS Onsite Certificated |
Flexiable Service | Low MOQ |
Flexiable Service | Customization and technical support |
