0
480x1280 resolution

6.86 inch 480x1280 bar shape ultra wide lcd display with hd-mi driver board

ND068602G09-12M-IPS
minimum order
1 piece
Country of Origin
Shenzhen
Quantity:
$40.00 - $45.00 / piece
Contact Now
add to cart
  • Type:TFT, Lcm
  • Display Size:6.86"
  • Supplier Type:manufacture
  • Place of Origin:Guangdong, China
  • Brand Name:New Display
  • Product Name:wide temperature ultra wide stretched bar shape TFT Lcd display
  • Resolution:480*1280
  • Size:6.86"
  • Interface:mipi
  • Application:Car GPS Navigator
  • Display mode:IPS
  • Viewing Angle:85/85/85/85(L/R/U/D)
  • Backlight:White LED
  • Brightness:600nits

6.86 inch 480x1280 bar shape ultra wide lcd display with hd-mi driver board





Specifications:















































































Module number



ND068602G09-12M-IPS


Resolution



480*1280



Active Area



292.32 x109.62



View angle



R/L/U/D 85/85/85/85 (Deg)



Mode



TFT



LCD Surface



Anti-glare,3H



Number of Colors



262K/16.2M



Electrical Interface



MIPI



Brightness



600 cd/m2



Contrast ratio



700:01:00



Outline dimension



160.588*60.2208*7.1



Gross weight



TBD



Backlight



WLED



LED Life (hrs.)



50K



Supply Voltage (V)



3.3V



Response time



25 (ms)



Operate temperature



-30-85 (°C)



Storage temperature



-30-85 (°C)





More information from ShenZhen New display CO.,LTD



1. Agent Brand:



* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd moulds, you can get the most competitive price for real products;



2.Application of our lcd panles:



Our products are widely used for banking machines, communication tools, household appliances, automobile instruments, mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.



3.Quality to be ensure:



All the panels are 100% original and brand new, no fake panels exists, so from Yasen Daco you can enjoy the real panels directly from original factory;



Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them;



4.Quickly delivery:



We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and to avoid Value Added Tax in china for you, so from Shenzhen New displayyou can get more convenient delivery;



5.long-term partner:



* Products are sold to more than 20 countries, so from ShenZhen New displayyou can get more stable supplying promise;



6. Super After-Sale service:



New display will support original factory technology service before and after sale for all your project,



you can send all the fack panel back and here return you a new panel;



7.the best TFT LCD solution:



*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/



To get the latest prices, pls feel free to contact us.
