21.5 inch tft lcd display

21.5 inch 1920x1080 LVDS interface TFT LCD display with led inverter HD-MI AD board

ND215HEH12-01
Quantity:
$40.00 - $60.00 / piece
Contact Now
add to cart
  • Type:TFT lcd, TFT
  • Display Size:21.5"
  • Supplier Type:factory
  • Place of Origin:Guangdong, China
  • Brand Name:New display
  • size:21.5
  • resolution:1920x1080
  • brightness:300 nits
  • Backlight:LED
  • Interface:LVDS
  • View angle:89/89/89/89
  • Contrast Ratio:1000:1
  • Operating temp:-30~85
  • RoHS/Halogen Free:RoHS/Halogen Free

21.5 inch 1920x1080 LVDS interface TFT LCD module with led inverter lvds cable HD-MI AD board





















































































Module number

ND215HEH12-01


Resolution



1920x1080



Pixel Pitch



0.2652(H) ×0.2652(V)



Active Area



509.184(H) × 286.416(V)



View angle



89/89/89/89



Mode



Normal Black



Pixel arrangement



RGB Vertical stripe



Support Color



16.7M



Electrical Interface



LVDS Interface with 2 pixel / clock



Brightness



300 cd/m2



Contrast ratio



1000:1



Outline dimension



533.2(H) × 312(V) × 10.5(D) typ.



Gross weight



2390 g



Backlight



LED



LED Life (hrs.)



30000



Supply Voltage (V)



12.8V



Response time



14 (ms)



Operate temperature



0~+50 (°C)



Storage temperature



-20~+60 (°C)







More information from Shenzhen New display CO.,LTD





1. Agent Brand:



* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd moulds, you can get the most competitive price for real products;



2.Application of our lcd panles:



Our products are widely used for banking machines, communication tools, household appliances, automobile instruments,



mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.



3.Quality to be ensure:



All the panels are 100% original and brand new, no fake panels exists, so from Shenzhen New display you can enjoy the



real panels directly from original factory;



Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the



packages have labels and serial number, you can check them;



4.Quickly delivery:



We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and



to avoid Value Added Tax in china for you, so from Shenzhen New displayyou can get more convenient delivery;



5.long-term partner:



* Products are sold to more than 20 countries, so from Shenzhen New display you can get more stable supplying promise;



6. Super After-Sale service:



Shenzhen New display will support original factory technology service before and after sale for all your project, you can send



allthefack panel back and here return you a new panel;



7.the best TFT LCD solution:



*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/



To get the latest prices, pls feel free to contact us.
