lcd dc voltage display

14.6 inch full hd 1920*1080 high resolution lcd screen

ND146FHD60P
minimum order
1 piece
Country of Origin
Shen Zhen
Quantity:
$20.00 - $40.00 / piece
Contact Now
add to cart
  • Type:TFT, TFT
  • Display Size:14.6"
  • Supplier Type:Manufacture
  • Place of Origin:Guangdong, China
  • Brand Name:New display
  • Size:14.6 inch
  • Resolution:1920*1080
  • Brightness:650
  • Backlight:LED
  • Contrast Ratio:500:1
  • Viewing Angle:85/85/85/85
  • Weight:130g

14.6 inch full hd 1920*1080 high resolution lcd screen















































































Screen Size14.6"
Aspect Ratio16:9
Display ModeTransmissive
Resolution1920*1080
PPI ( Pixel per inch )133
Module/Panel Size(mm)
336.249(H) x 198.46(V) x 7.73(D)(Exclude nut pole)
Active Area(mm)
323.136(H) x 181.764(V)
Dot Pitch(mm)
0.1683(H) x 0. 1683 (V)
V iewing Angle (Tpy.)θT/θB/θL/θR85/85/85/85
Viewing direction6 O'Clock
NTSC50%
Luminance(nits)650
Contrast Ratio500
Response Time(ms)25
Weight (g)130
InterfaceRGB
Operation Temperature-20~70
Storage Temperature -30~80








More information from Shenzhen New display CO.,LTD



1. Agent Brand:
* AUO/CPT/CMO/ /Innolux/ TianMa five brands tft lcd moulds, you can get the most competitive price for real products;
2.Application of our lcd panles:
Our products are widely used for banking machines, communication tools, household appliances, automobile instruments, mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.
3. Quality to be ensure:
All the panels are 100% original and brand new, no fake panels exists, so from Shenzhen New display you can enjoy the real panels directly from original factory;
Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them;4.long-term partner:
* Products are sold to more than 20 countries, so from Shenzhen New display you can get more stable supplying promise;
5. Super After-Sale service:
Shenzhen New display will support original factory technology service before and after sale for all your project, you can send all the fack panel back and here return you a new panel;
6.the best TFT LCD solution:
*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/
To get the latest prices, pls feel free to contact us.
