bar type lcd

12.3 inch ultra wide stretched monitor bar type touch screen lcd display

123
minimum order
1 piece
Supply Ability
200000piece / Month
Country of Origin
Shenzhen
Quantity:
USD100.00 - USD145.00 / piece
Contact Now
add to cart
  • Place of Origin:CN;GUA
  • Type:Lcm
  • Brand Name:Newdisplay
  • Model Number:123
  • Size:12.3
  • Resolution:1280x720
  • Display mode:Black
  • Viewing Angle:89/89/89/89
  • Backlight:WLED
  • Brightness:1000 nits

12.3 inch ultra wide stretched monitor bar type touch screen lcd display

Specifications:

Module number

S123WU01

Resolution

1920*720

Pixel Pitch

0.05075(H)×RGBx0.15225(V)

Active Area

292.32 x109.62

View angle

R/L/U/D 80/80/80/80 (Deg)

Mode

TFT

LCD Surface

Anti-glare,3H

Number of Colors

262K/16.2M

Electrical Interface

Digital, LVDS(1ch, 6/8 bit)

Brightness

1000 cd/m2

Contrast ratio

700:01:00

Outline dimension

308.1*134.86*7.3

Gross weight

TBD

Backlight

WLED

LED Life (hrs.)

50K

Power Consumption (W)

9.15(Typ.)

Supply Voltage (V)

3.3V

Response time

25 (ms)

Operate temperature

-30-85 (°C)

Storage temperature

-30-85 (°C)

More information from ShenZhen New display CO.,LTD

1. Agent Brand:

* AUO/CPT/CMO//Innolux/TianMafive brands tft lcd moulds, you can get the most competitive price for real products;

2.Application of our lcd panles:

Our products are widely used for banking machines, communication tools, household appliances, automobile instruments, mobile phone, video door phone, E-book, stock mobile, MP5, tablet PC, GPS navigator and so on.

3.Quality to be ensure:

All the panels are 100% original and brand new, no fake panels exists, so from Yasen Daco you can enjoy the real panels directly from original factory;

Original package and Seal for batch orders, all the products are in original package from original factory directly, and all the packages have labels and serial number, you can check them;

4.Quickly delivery:

We also have international logistic center in Hongkong to support your batch orders to be delivered from Hongkong directly and to avoid Value Added Tax in china for you, so from Shenzhen New displayyou can get more convenient delivery;

5.long-term partner:

* Products are sold to more than 20 countries, so from ShenZhen New displayyou can get more stable supplying promise;

6. Super After-Sale service:

New display will support original factory technology service before and after sale for all your project,

you can send all the fack panel back and here return you a new panel;

7.the best TFT LCD solution:

*more tft lcd model detail information including size, resolution, brightness, operating temperature or life time etc in our web site or alibaba website: http://www.tft-lcd-panels.com/

To get the latest prices, pls feel free to contact us.
